CUp to 19,500 lbs GVWR
Up to 12,450 lbs Payload
WEIGHTS
GVWR
CLASS 4 16,000 lbs
CLASS 5 19,500 lbs
PAYLOAD
CLASS 4 8,950 lbs
CLASS 5 12,450 lbs
REAR AXLE
13,670 lbs
FRONT AXLE
7,050 lbs
CHASSIS CURB WEIGHT (CW)
7,050 lbs
CHASSIS CURB WEIGHT REAR (CWR)
3,200 lbs
HIGH VOLTAGE
HV BATTERY CAPACITY
132 kWh
HV BATTERY VOLTAGE
600 V
AC LEVEL 2 CHARGE 20%-100%
6 hrs @ 20 kW
DC FAST CHARGE 20%-80%
40 min @ 135 kW
HV BATTERY LOCATION
INSIDE FRAME
CHARGE CONNECTION
CCS1
DIMENSIONS
CHASSIS/CAB LENGTH
234 in
WHEELBASE (WB)
138 in
HEIGHT (CAB)
92.5 in
WIDTH (CAB)
91 in
HEIGHT (TOP OF FRAME)
32 in
WIDTH (CHASSIS)
34 in
GROUND CLEARANCE (LOWEST POINT)
8 in
TURNING CIRCLE
41 ft
PERFORMANCE
RANGE (WLTP)
CLASS 4 165 miles
CLASS 5 150 miles
TOP SPEED
65 mph
POWER
(CONTINUOUS/PEAK)
150 / 270 hp
TORQUE
(CONTINUOUS/PEAK)
170 / 330 lb/ft
TRACTION MOTOR LOCATION REAR E-AXLE
ePTO #1 15 kW
ePTO #2 30 kW
CHASSIS
APPROACH ANGLE (
FRONT) 19 degrees
DEPARTURE ANGLE (REAR)
17 degrees
BRAKE SYSTEM
HYDRAULIC
BRAKE TYPE (F/R)
DISC/DISC
SAFETY FEATURES
ABS/ABD/ECS/TPMS/PWS
ADAS FEATURES
AEB/LDW
FRONT SUSPENSION
LEAF
REAR SUSPENSION
LEAF
TIRE SIZE
225/70 R19.5
CAB
LOW VOLTAGE NOMINAL
24 V
HEATING CAPACITY
3,000 W
COOLING CAPACITY
4,500 W
AC REFRIGERANT
1234YF
CRUISE CONTROL
STD
SEATING
2
DRIVERS SEAT ADJUSTMENT
4 WAY ADJUSTABLE AND HEATED
REAR VIEW CAMERA
360 DEGREE CAMERA VIEWS
REARVIEW MIRRORS HEATED/ELEC. ADJUST
STD
HEADLIGHTS/EXTERIOR LIGHTS
LED
INFOTAINMENT
AM, FM, BLUETOOTH, USB-A
DASHBOARD/INFOTAINMENT SCREEN SIZE
7 in / 12.3 IN
UPFITTER
FRONT AXLE TO BACK OF CAB (AC)
21 in
FRONT BUMPER TO FRONT AXLE (BA)
44 in
FRONT BUMPER TO BACK OF CAB (BBC)
65 in
CARGO BODY LENGTH (FROM/TO) (BL)
12 – 16 ft
CAB TO AXLE (CA)
111 in
CAB TO BODY CLEARANCE (CB)
4 in
CUp to 19,500 lbs GVWR
Up to 12,450 lbs Payload
WEIGHTS
GVWR
CLASS 5 19,500 lbs
CLASS 6 19,510 lbs
PAYLOAD
CLASS 5 11,750 lbs
CLASS 6 11,760 lbs
FRONT AXLE
7,050 lbs
CHASSIS CURB WEIGHT (CW)
7,750 lbs
CHASSIS CURB WEIGHT REAR (CWR)
3,480 lbs
HIGH VOLTAGE
HV BATTERY CAPACITY
132 kWh
HV BATTERY VOLTAGE
600 V
AC LEVEL 2 CHARGE 20%-100%
6 hrs @ 20 kW
DC FAST CHARGE 20%-80%
40 min @ 140 kW
HV BATTERY LOCATION
INSIDE FRAME
CHARGE CONNECTION
CCS1
DIMENSIONS
CHASSIS/CAB LENGTH
328 in
WHEELBASE (WB)
177 in
HEIGHT (CAB)
116 in
WIDTH (CAB)
79 in
HEIGHT (TOP OF FRAME)
32 in
WIDTH (CHASSIS)
91 in
GROUND CLEARANCE(LOWEST POINT)
8 in
TURNING CIRCLE
59 ft
PERFORMANCE
RANGE (WLTP)
150 miles
TOP SPEED
65 mph
POWER (CONTINUOUS/PEAK)
150 / 270 hp
TORQUE (CONTINUOUS/PEAK)
170 / 330 lb/ft
TRACTION MOTOR LOCATION
REAR E-AXLE
ePTO #1
15 kW
ePTO #2 30 kW
CHASSIS
APPROACH ANGLE (FRONT)
19 degrees
DEPARTURE ANGLE (REAR)
11 degrees
BRAKE SYSTEM
HYDRAULIC
BRAKE TYPE (F/R)
DISC/DISC
SAFETY FEATURES
ABS/ABD/ESC TPMS/PDW
ADAS FEATURES
AEB/LDW
FRONT SUSPENSION
LEAF
REAR SUSPENSION
LEAF
TIRE SIZE
225/70 R19.5
CAB
LOW VOLTAGE NOMINAL
24 V
HEATING CAPACITY
3,000 W
COOLING CAPACITY
4,500 W
AC REFRIGERANT
1234YF
CRUISE CONTROL
STD
SEATING
2
DRIVER SEAT ADJUSTMENT
4 WAY
REAR VIEW CAMERA
360 DEGREE CAMERA VIEWS
REARVIEW MIRRORS HEATED/ELEC. ADJUST
STD
HEADLIGHTS/EXTERIOR LIGHTS
LED
INFOTAINMENT
AM, FM, BLUETOOTH, USB-A
DASHBOARD/INFOTAINMENT SCREEN SIZE
7 in / 12.3 in
UPFITTER
FRONT AXLE TO BACK OF CAB (AC)
21 in
FRONT BUMPER TO FRONT AXLE (BA)
44 in
FRONT BUMPER TO BACK OF CAB (BBC)
65 in
CARGO BODY LENGTH (FROM/TO) (BL)
18 – 22 ft
CAB TO AXLE (CA)
156 in
CAB TO BODY CLEARANCE (CB)
4 in
OPTIONS
DAY BED
OPT
LOW CAB VARIANT
OPT
Purpose-built Commercial Vehicles
Assembled in the US, ZM Trucks is a manufacturer and seller of zero-emission, urban environment commercial vehicles. Designed in Asia, sourced from a global supply chain.
ZM Trucks have achieved a competitive total cost of ownership (TCO) with diesel trucks in select segments, paving the way for companies of all sizes to seamlessly transition from diesel to zero-emission solutions without compromise.
ZM Trucks utilize electric drive systems not merely because they are green, but because the technology is superior to diesel engine platforms for the intended use cases.
